PID Temperature Controller with Universal Input (TC, RTD)
Emko
PID Temperature Controller with Universal Input (TC, RTD)
Universal process input (TC,RTD)
Automatic adaptation of PID coefficients to the system with
Self-Tune (Step Response Tuning) and Auto-Tune operation
2 Relays and 1 SSR drive output
Soft Start Output For Resistance Durability
4 Digits process (PV) and 4 Digits set value (SV) display
Configurable ON/OFF, P, PI, PD, and PID control forms
Programmable Heating or Cooling Functions for Control Output
Alarm Functions for Alarm Output
SET Value Limitation For System Protection
Sensor Break Protection
Share
| Features | Descriptions |
| Physical Features | |
| Dimensions | 48 mm x 48 mm 95 mm |
| Protection Class | NEMA 4X (IP65 at front, IP20 at rear) |
| Installation | Fixed Installation |
| Storage / Operating Temperature | -40°C to +85°C / 0°C to +50°C |
| Storage / Operating Humidity | 90 % max. (None condensing) |
| Electrical Features | |
| Supply Voltage and Power | 230 Vac (+%15) 50/60 Hz. 1.5 VA 115 Vac(+%15) 50/60 Hz. 1.5 VA 24 Vac(+%15) 50/60 Hz. 1.5 VA 24 Vac/dc (+%15, +%10) 50/60 Hz. 1.5 VA |
| Sensor Inputs | J, K, R, S, T (IEC584.1) (ITS90) Selectable from parameters PT-100 (IEC751) (ITS90) |
| Optional Sensor Inputs | |
| Scale | Fe CuNi -200°C,900°C NiCr Ni -200°C,1300°C Pt13%Rh 0°C,1700°C Pt10%Rh 0°C,1700°C Cu CuNi -200°C,400°C PT 100 -200°C,650°C PT 100 -199.9°C,650.0°C |
| Accuracy | ± % 0.25 of full scale for Thermocouple and Thermoresistance |
| Output | |
| Relay Output | 5A@250 Vac at resistive load 5A@250 Vac at resistive load (Alarm Output) |
| SSR Output | Maximum 20 mA @ 12 Vdc |
| Analogue Output | |
| Optional Outputs | |
| Control | |
| Control Form | Programmable On / Off, P, PI, PD, and PID |
| Reading Frequency | 3 readings per second |
| Communication Protocols | |
| Approvals | GOST-R, CE |
